Clearaudio Jubilee MC

mirre — Sun, 26 Apr 2020 21:27:08 +0000

Inlägget Clearaudio Jubilee MC dök först upp på Veteran HiFi.

Clearaudio Nano Phono V2

mirre — Sun, 26 Apr 2020 20:48:41 +0000

Specifikation

* AMPLIFICATION @ 1 KHZ: 34 dB to 48 dB (MM mode)
54 to 68 dB (MC mode)
* INPUT LOAD: 47 kOhm / 220 pF / MM mode
Individual / User / MC mode
* MM / MC INPUT: switchable by jumper (at bottom)
* SUBSONIC FILTER: switchable (at bottom)
*RIAA: delay time: 75 μs / 318 μs / 3180 μs
* RIAA ACCURACY: ± 0.4dB
* THD: 0,04%
* SIGNAL TO NOISE RATIO: 81 dB (A) (MM – Mode)
70 dB (A) (MC – Mode)
* CHANNEL SEPARATION: > 80dB (1kHz)
* MAX. OUTPUT VOLTAGE: 10V eff. (1kHz), 0-10 adjustable
* POWER SUPPLY: ±18V DC (external wall power supply, plastic housing)
* OUTPUT CONNECTIONS: Asymmetrical (RCA)
* POWER CONSUMPTION: Max. consumption: 2.3 Watt
Consumption in operation: 2.3 Watt
Standby mode: < 0.3 Watt
Off mode: 0.0 Watt
* WEIGHT: Approx. 500 g (preamp and power supply)
* DIMENSIONS (W/D/H in mm): 85 x 106 x 25

Inlägget Clearaudio Nano Phono V2 dök först upp på Veteran HiFi.

Clearaudio Balance V2

mirre — Sun, 26 Apr 2020 20:17:59 +0000

Specifikation:

* MODE: MM/MC (Subsonic filter switchable)
* AMPLIFICATION @ 1 KHZ: +46 dB (MM mode)
+66 dB (MC mode)
* INPUT IMPEDANCE: 47 kOhm / 270 pF / MM mode
500 Ohm / 270 pF / MC mode
* MM / MC INPUT: switchable (on bottom panel)
* RIAA: 75 μs / 318 μs / 3180 μs, 2 passive filter
* RIAA ACCURACY: ± 0.1 dB
* THD: < 0.001% (IEC A)
* SIGNAL TO NOISE RATIO: -78 db (MM mode)
-69 dB (MC mode)
* CHANNEL SEPARATION: > 92 dB (@ 1 kHz)
* MAX. OUTPUT VOLTAGE: >12 V (@ 1 kHz)
* SUBSONIC FILTER: 20 Hz (–6 dB / Oct.; switchable on bottom panel, on each channel)
* POWER CONSUMPTION: Max. consumption: 6.6 watts
Standby mode: <0.3 watts
Off mode: 0.0 watts
* OPERATION VOLTAGE: ± 18 V DC (+21V DC external power supply; 1.4m cable length)
* OUTPUT CONNECTIONS: Unbalanced (RCA)
Balanced (XLR)
Headphone output (Jack 6.3mm)
* TOTAL WEIGHT: Approx. 2.3 kg (Preamp)
Approx. 1.4 kg (power supply)
* DIMENSIONS (W/D/H in mm): Preamp: 240 x 145 (158 with RCA) x 62
Power Supply: 240 x 145 x 62

Inlägget Clearaudio Balance V2 dök först upp på Veteran HiFi.

Clearaudio MC Essence

mirre — Sun, 04 Dec 2016 01:15:21 +0000

Stylus shape: Micro Line
Cantilever: Boron
Coil material: OFC – copper
Frequency Response: 20 Hz – 40 kHz
Compliance: 9/9 μ/mN
Rek. tracking force: 2.0 gr ( ± 0.2 gr)
Channel separation: >32 dB
Output voltage: 0,4 mV at 5 cm/s
Cartridge impedance: 11 Ohms
Cartridge body: Aluminium-Magnesium alloy with ceramic surface layer
Total weight: 8,0 gram

Inlägget Clearaudio MC Essence dök först upp på Veteran HiFi.

Clearaudio Superwire

mirre — Fri, 15 May 2015 15:53:51 +0000

4 colours, super high flexible, twisted, high grade OFC, low inductance and impedance

Inlägget Clearaudio Superwire dök först upp på Veteran HiFi.

Clearaudio Goldfinger Statement

mirre — Fri, 08 May 2015 09:23:57 +0000

For the first time in a cartridge, the MC Goldfinger Statement features twelve magnets, perfectly matched and symmetrical enabling the system to reach a dynamic range of 100 decibels. For the Clearaudio engineering team this represents the fulfilment of an audiophile dream that seemed long unattainable.

Material: 14-karat gold

Stylus shape Micro HD

Output voltage: 0.7 mV at 5 cm/s

Inlägget Clearaudio Goldfinger Statement dök först upp på Veteran HiFi.

Clearaudio da Vinci V2

mirre — Fri, 08 May 2015 09:13:40 +0000

Classic design for contemporary art, which represents the current state of what is possible. The aluminium body of the MC da Vinci V2 is characterised by its extra hard, 30-micron thick ceramic coating that delivers extremely efficient resonance suppression.

Output voltage: 0.6 mV at 5 cm/s

Inlägget Clearaudio da Vinci V2 dök först upp på Veteran HiFi.

Clearaudio Stradivari V2

mirre — Fri, 08 May 2015 09:09:14 +0000

Stradivari is synonymous with the absolute master-class of creating musical instruments.

An impressive 95¬decibel dynamic range is made possible through the use of patented V2 technology and of the finest high-end materials.

Ebony wood with metal platter

Output voltage: 0.6 mV at 5 cm/s

Inlägget Clearaudio Stradivari V2 dök först upp på Veteran HiFi.

Clearaudio Concerto V2

mirre — Fri, 08 May 2015 09:01:55 +0000

With a dynamic range of up to 70 decibels and a total weight of only seven grams, the MC Concerto V2 qualifies itself for the top league of moving coil cartridges.

Output voltage: 0.6 mV at 5 cm/s
